博科300光纤交换机概述：

Brocade 300（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）是一款吞吐量达8 Gbit/秒的光纤通道交换机，是专为小型SAN或大型SAN边缘设计的经济型入门级解决方案。它使中小型企业可以简化IT基础设施，提高系统性能，最大限度地发挥虚拟服务器部署的价值并降低总体存储成本。

经济合算的SAN技术

Brocade 300（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）能够以入门级解决方案的价格提高卓越的性能和强大的功能。它将1、2、4和8 Gbit/秒的光纤通道吞吐量自动侦测与旨在增强光纤架构性能的功能结合在一起。Brocade 300能够提供如此强大的功能，而每端口的功耗还不到2.5瓦，因此，具有出色的功率和冷却效率。

Brocade 300（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）采用了一种无阻塞架构，最多支持24个端口同时以8 Gbit/秒（全双工）的速率运行，并且不会出现超量使用现象——总带宽为192 GB/秒。另外，增强的Brocade ISL干线合并还可以支持最高吞吐量达64 GB/秒的单一逻辑高速干线。

简化的管理

借助Brocade EZSwitchSetup安装向导，可以轻松便捷地安装和配置Brocade 300（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008），交换机的配置、部署和管理变成了简单的三步点击操作。在多交换机环境中，博科网络顾问软件（Brocade Network Advisor）可提供全面的数据中心Fabric架构管理功能，包括博科骨干网、交换机和适配器的配置、监控和管理。Brocade 300 可兼容Microsoft Simple SAN，另外还带有一个可通过简化固件升级和系统日志文件下载来提高维护简便性和错误记录的USB端口。

简单快捷的扩展

Brocade 300（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）易于部署和管理，并且可以轻松集成到新的和现有的IT环境中。Brocade 300具有按需端口扩展（Ports on Demand）（端口可由8个扩展至16或24个）等多种功能，因此，企业可以根据需要随时扩展自己的存储网络而不会影响业务正常运行。另外，企业可以先部署4 Gbit/秒的SFP，然后根据需要升级为8 Gbit/秒的SFP。

高级连接选项

Brocade300可作为一款全光纤交换机或作为一款Brocade Access Gateway（接入网关）进行部署，能提供到任一SAN网络的连接（其默认模式设置是一款交换机）。接入网关模式采用N_Port ID虚拟化（NPIV）交换机标准，可将光纤通道连接作为逻辑设备提呈到SAN Fabric架构中。如果利用支持NPIV技术的交换机和导向器进行连接，接入网关模式下的Brocade 300可以连接到Brocade、McDATA或其它SAN Fabric架构。

Brocade光收发模块

Brocade 8 Gbit/sec交换机需要Brocade光收发模块。这种模块有多种型号，可以满足不同的速度和距离要求。这些小型可插拔（SFP）模块最适合用于Brocade 8Gbit/sec产品，可以最大限度地提高性能，降低功耗，帮助确保关键任务应用的最高可用性。（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）

行业标准遵从

Brocade产品符合行业标准，而且采用了普遍接受的工程实践和流程。（博科光纤交换机|博科300|BR-310-0008|BR-320-0008|BR-340-0008|BR-360-0008）

博科300光纤交换机特性：

•       为入门级SAN提供价格合理的基础设备

•       在一个1U机架中为最多24个端口提供8 Gbit/秒的1：1性能

•       借助Brocade EZSwitchSetup安装向导简化配置和管理，并且可以与Microsoft Simple SAN兼容

•       包括Brocade Network Advisor Professional（博科网络顾问软件专业版），可实现多交换机监控和管理

•       提供“边增长边付费”式可扩展性，利用按需端口扩展（PoD）功能将端口数量从8个扩展到16或24个

•       提供双功能，既可作为全光纤SAN交换机，也可以用作支持N_Port ID Virtualization（NPIV）的Brocade接入网关设备

•       提供适应性网络服务，如服务质量（QoS），帮助企业优化整合虚拟环境中的应用性能

•       借助1、2、4和8 Gbit/秒自动侦测功能，保护现有设备投资

•       将带宽增长与功耗降低结合起来，提高能效

•       面向未来的投资保护，使企业可以先部署4 Gbps SFP，然后在需要时升级到8 Gbps SFP+

博科300光纤交换机规格：

Systems Architecture

Fibre Channel ports

•       Switch mode (default): 8-, 16-, and 24-port configurations (8-port increments through Ports on Demand licenses); universal (E, F, M, FL) ports

•       Access Gateway Default Port Mapping: 16 F_Ports, 8 N_Ports

Scalability

•       Full fabric architecture with 239 switches maximum

Certified maximum

•       Single Brocade FOS fabric: 56 domains, 19 hops

•       Single Brocade M-EOS fabric: 31 domains, 3 hops

•       Larger fabrics certified as required; consult Brocade or OEM SAN design documents for configuration details

Performance

•       1.063 Gbit/sec line speed, full duplex; 2.125 Gbit/sec line speed, full duplex; 4.25 Gbit/sec line speed, full duplex; 8.5 Gbit/sec line speed, full duplex; auto-sensing of 1, 2, 4, and 8 Gbit/sec port speeds; optionally programmable to fixed port speed; speed matching between 1, 2, 4, and 8 Gbit/sec ports

ISL Trunking

•       Frame-based trunking with up to eight 8 Gbit/sec ports per ISL trunk with optional license; up to 64 Gbit/sec per ISL trunk (8 ports × 8 Gbit/sec [data rate])

•       Exchange-based load balancing across ISLs with DPS included in Fabric OS

Aggregate bandwidth

•       192 Gbit/sec: 24 ports × 8 Gbit/sec (data rate)

Maximum fabric latency

•       700 ns with no contention, cut-through routing at 8 Gbit/sec

Maximum frame size

•       2112-byte payload

Frame buffers

•       700 dynamically allocated, 484 maximum per port

Classes of service

•       Class 2, C lass 3, C lass F (inter-switch frames)

Port types

•       FL_Port, F_Port, M_Port (Mirror Port), and E_Port; self-discovery based on switch type (U_Port); optional port type control

•       Brocade Access Gateway mode: F_Port and NPIV-enabled N_Port

Data traffic types

•       Fabric switches supporting unicast, multicast (255 groups) and broadcast

Media types

•       8 Gbit/sec: Requires Brocade hot-pluggable SFP+, LC connector; 8 Gbit/sec Short-Wavelength Laser (SWL); 8 Gbit/sec Long-Wavelength Laser (LWL); distance depends on fiber-optic cable and port speed

•       4 Gbit/sec: Requires Brocade hot-pluggable, Small Form-factor Pluggable (SFP), LC connector; 4 Gbit/sec Short-Wavelength Laser (SWL); 4 Gbit/sec Long-Wavelength Laser (LWL); 4 Gbit/sec Extended Long-Wavelength Laser (ELWL); distance depends on fiber-optic cable and port speed

USB

•       1 USB port for firmware download, support save, and configuration upload/download

Fabric services

Note: Some fabric services do not apply or are unavailable in Brocade Access Gateway mode

•       Simple Name Server (SNS); Registered State Change Notification (RSCN); NTP v3; Reliable Commit Service (RCS); Dynamic Path Selection (DPS); Brocade Advanced Zoning (default zoning, port/WW N zoning, broadcast zoning); NPIV; N_Port Trunking; FDMI; Management Server; FSPF; Fabric Watch; Extended Fabrics; ISL Trunking; Advanced Performance Monitoring; Adaptive Networking (per data flow QoS, Ingress Rate Limiting, Traffic Isolation, Top Talkers; licensing varies); IPoFC, Integrated Routing; Frame Redirection; Port Fencing; BB credit recovery

Options

•       Rack-mount rail kits (fixed, slide, mid-mount)

Management

Management

•       HTTP, SNMP v1/v3 (FE MIB, FC Management MIB), Telnet; Auditing, Change Management tracking, Syslog; Brocade Advanced Web Tools, Brocade Fabric Watch; EZSwitchSetup wizard, Brocade Data Center Fabric Manager (DCFM), Brocade Fabric Manager (optional, FOS environments only), Brocade EFCM 9.x (optional), command line interface; SMI-S compliant, SMI-S scripting toolkit; Administrative Domains; trial licenses for add-on capabilities

Security

•       DH-CHAP (between switches and end devices), HTTPS, IPsec, IP Filtering, LDAP, Port Binding, RADIUS, Role-Based Access Control (RBAC), Secure Copy (SCP), Secure RPC, SSH v2, SSL, Switch Binding, Trusted Switch

Management access

•       10/100 Ethernet (RJ-45), in-band over Fibre Channel; serial port (RJ-45); USB; call-home integration enabled through Brocade EFCM and Brocade Fabric Manager

Diagnostics

•       POST and embedded online/offline diagnostics, including RAStrace logging, environmental monitoring, non-disruptive daemon restart, FCping and Pathinfo (FC traceroute), port mirroring (SPAN port)

Mechanical

Enclosure

•       Non-port to port side airflow; 1U, 19-inch EIA-compliant, power from port side

Size

•       Width: 42.88 cm (16.88 in)

•       Height: 4.29 cm (1.69 in)

•       Depth: 30.66 cm (12.07 in)

System weight

•       4.2 kg (9.30 lbs), without SFP/SFP+ media

Environment

Temperature

•       Operating: 0°C to 40°C (32°F to 104°F)

•       Non-operating and storage: -25°C to 70°C (-13°F to 158°F)

Humidity

•       Operating: 10% to 85% non-condensing

•       Non-operating and storage: 10% to 95% non-condensing

Altitude

•       Operating: Up to 3000 meters (9842 feet)

•       Non-operating and Storage: Up to 12 km (39,370 feet)

Shock

•       Operating: 20 g, 6 ms half-sine

•       Non-operating and storage: Half sine, 33 g 11 ms, 3/eg Axis

Vibration

•       Operating: 0.5 g sine, 0.4 grms random, 5 to 500 Hz

•       Non-operating and storage: 2.0 g sine, 1.1 grms random, 5 to 500 Hz

Heat dissipation

•       Maximum 24 ports: 195 BTU/hr

CO2 emissions

•       210 kg per year (with 16 ports at 0.42 kg/kWh)

•       1.09 kg per Gbit/sec per year

Airflow

•       Maximum 23 C FM (cu. ft./min.); nominal 18 C FM

Power

Power supply

•       Single, fixed power supply

Power inlet

•       C13

Input voltage

•       85 to 264 VAC nominal

Frequency

•       47 to 63 Hz

Power consumption

•       Nominal 48 watts; maximum 57 watts with 24 ports at 8 Gbit/sec
